Description
xThe Staubli PV-ADS4-EVO 2A/6 is a high-performance panel receptacle (male) from the renowned MC4-Evo 2 series, designed for demanding photovoltaic applications. Engineered for durability, compatibility, and optimal power transfer, it supports cross-sections of 4 mm² and 6 mm² conductors, ensuring reliable and safe connections in harsh environments.
Key Features
- MC4-Evo 2 compatible panel receptacle for photovoltaic systems
- Accommodates 4 mm² and 6 mm² conductor cross-sections
- Designed for fast and secure panel mounting
- High current-carrying capacity with IP68 rated protection
Specifications
xConnector Type
MC4-Evo 2, Panel Receptacle, Male
Conductor Cross-section
4 mm² / 6 mm²
Rated Current
Up to 45 A
Rated Voltage (DC)
1500 V DC (IEC), 1500 V DC (UL)
Contact Resistance
< 0.25 mΩ
Degree of Protection
IP68 (mated), IP2X (unmated)
Temperature Range
-40°C to +85°C
Flammability Rating
Insulation Material
High-performance plastic (PPE/PS)
Standards
IEC 62852, UL 6703, TÜV certified
