Description
xThe Staubli MC4 Pin for male connectors is a high-quality contact element engineered for use in photovoltaic systems. Designed for 4 – 6mm² conductors, it ensures safe, low-resistance connections with excellent long-term reliability. Its precision manufacturing and silver-plated contact surface guarantee maximum efficiency and durability in demanding environments.
Key Features
- Compatible with Staubli MC4 male connectors for 4 – 6mm² cables
- High conductivity silver-plated contact for minimal power loss
- Durable design ensuring long-term stability in PV systems
- Reliable performance under outdoor and harsh conditions
Specifications
xType
MC4 Pin for Male Connector
Application
Photovoltaic Connections
Conductor Cross-Section
4 – 6 mm²
Contact Material
Rated Voltage
1000 VDC (IEC) / 1500 VDC (UL)
Rated Current
Up to 30 A
Contact Resistance
< 0.25 mΩ
Insulation Material
PA (Polyamide), UV Resistant
Temperature Range
-40°C to +85°C
Flammability Rating
Connection Method
Standards
IEC 62852 / UL 6703
