Description
xThe Noark Ex9BP‑JX 4‑pole DC miniature circuit breaker is engineered for reliable protection in high-voltage solar and DC power systems. It safeguards circuits against overloads and short circuits up to 25 A, with a rated operational voltage up to 1000 V DC. Designed for DIN‑rail mounting, it’s compatible with photovoltaic balance‑of‑system (BOS) applications and features thermal‑magnetic tripping characteristics (C‑ and K‑curves). Supported accessories include auxiliary contacts, shunt‑trip, and under‑voltage releases for advanced control.
Key Features
- 4‑pole breaker for comprehensive multi‑string DC protection
- Rated for up to 1000 V DC and 25 A nominal current
- Thermal‑magnetic C‑curve ensures fast tripping on overloads
- High short‑circuit breaking capacity of 10 kA
Specifications
xProduct Name
Noark Ex9BP‑JX Miniature DC Circuit Breaker, 4‑Pole
Rated Operational Voltage
Up to 1000 V DC (per pole)
Rated Current
25 A
Poles
4
Tripping Characteristics
C‑curve (9.6–14.4 × In), optionally K‑curve
Short-Circuit Breaking Capacity (Icu)
10 kA @ DC
Mounting
35 mm DIN rail, 18 mm per pole
Mechanical Lifespan
20,000 operations
Electrical Lifespan
6,000 switching cycles
Ambient Operating Temperature
–30 °C to +70 °C
Standards Compliance
IEC/EN 60947‑2, IEC/EN 60947‑2 Annex P, UL 1077
Standards Compliance
IEC/EN 60947‑2, IEC/EN 60947‑2 Annex P, UL 1077
