Solar Mounting Structures
Vectis and Lizard mounting systems for IBR, Klip-Lok, tile and flat roofs, ground mounts and solar carports.
-
Lizard tile roof supportVendor: LizardSKU: 30111The Lizard Tile Roof Support is a specialised mounting solution crafted for photovoltaic (PV) systems specifically tailored for tile roofs. Compatible with the Lizard standard profile (10103), this support system is meticulously engineered to ensure hassle-free installation and steadfast durability. Crafted from premium-grade materials,...
-
Lizard End clamp, V2, not assembled, 30 - 50mmVendor: LizardSKU: 10203The Lizard End Clamp, V2 (Part No. 10203) is designed for use in photovoltaic (PV) mounting systems with Klip Lok profiles. It accommodates module heights between 30 - 50mm. The clamp is supplied unassembled, offering flexibility during installation. It is part of the comprehensive...
-
Vectis Carport beam, 4500mmVendor: VectisSKU: A5001070The Vectis Carport Beam is a key component of the aluminium Waterproof Carport System, designed to support solar energy solutions in large, underutilised spaces. This system enhances sustainability while providing year-round protection with shaded, waterproof parking. The pre-assembled structure ensures stability, minimises installation time,...
-
Vectis Carport NW rail, 5000mmVendor: VectisSKU: A5001030The Vectis Carport NW Rail is an integral component of the aluminium Waterproof Carport System, designed to optimise space by supporting solar energy installations. This durable structure provides year-round shade and protection while facilitating energy generation. The pre-assembled system ensures quick and secure installation,...
-
Vectis Grounding lugVendor: VectisSKU: A0001000The Vectis Grounding Lug is an essential component of the Vectis Aluminium Ground Mounting system, designed to facilitate secure and efficient installation of PV modules on flat, concrete platforms. Crafted from extruded Anodised Al 6005-T6 aluminium, this grounding lug offers robust durability and excellent...
-
Vectis Carport cover plate, 4500mmVendor: VectisSKU: A5001110Vectis Carport Cover Plate The Vectis Carport Cover Plate is a key component of the aluminium Waterproof Carport System. This solution is designed to mount energy generation systems on large, underutilised surfaces while providing shaded and dry parking spaces throughout the year. Its preassembled...
-
Vectis Earthing clip, Kliplok short railVendor: VectisSKU: A3001010The Vectis Earthing Clip for Kliplok short rail is a component of the rail-less mounting system for PV panels on Kliplock roof sheeting. It is used to provide an electrical grounding connection for the PV panel installation. The Vectis Earthing Clip is designed to...
-
Vectis Carport EPDM rubber string, 35 x 6Vendor: VectisSKU: A5001120The Vectis Carport EPDM rubber string is an essential component of the aluminium Waterproof Carport system. This waterproof carport structure is designed for mounting energy generation solutions on large, unused surfaces. In addition to energy production, it provides shaded, dry, and cool parking spaces...
-
Vectis Carport beam connectorVendor: VectisSKU: A5001090The Vectis Carport Beam Connector is an integral component of the Vectis Waterproof Carport system, crafted from high-quality anodised Al 6005-T6 aluminium. Designed for durability, ease of installation, and weather resilience, it supports the mounting of energy generation solutions on expansive, underutilised surfaces. This...
-
Vectis Groundmount rail spliceVendor: VectisSKU: A4001070The Vectis Groundmount Rail Splice is an essential component of the Vectis Aluminium Ground Mounting System, designed for efficient and secure solar panel installations. Featuring a pre-assembled structure with a main support beam, it streamlines installation and minimises labour time. Engineered for stability on...
-
Vectis Carport GN rail spliceVendor: VectisSKU: A5001060The Vectis Carport GN rail splice forms part of the aluminium waterproof carport system, designed for mounting energy generation solutions on large, unused surfaces. In addition to energy production, it provides cool, shady, and dry parking spaces year-round. This waterproof solar carport is compatible...
-
Vectis Carport GN rail, 4500mmVendor: VectisSKU: A5001040The Vectis Carport GN Rail is a key component of the aluminium waterproof carport system, designed for mounting solar energy solutions on underutilised surfaces. This innovative structure provides efficient energy generation while offering year-round shaded and dry parking. Ideal for ground mounting in residential...
-
Vectis Carport W rail clampVendor: VectisSKU: A5001170The Vectis Carport W Rail Clamp is an essential component of the aluminium waterproof carport system. Designed for large, unused surfaces, it supports energy generation while providing year-round shaded and dry parking. Its preassembled structure enhances stability and simplifies installation, making it an ideal...
-
ARaymond Edge clip, cable tie baseVendor: AraymondSKU: 208738001Cable Routing Clips A large scope of solutions for fixing cables over, along or on the side of module edges or rail structures, in order to improve wiring. The intended use for the cable tie base clip is when several cables or strands...
-
Vectis Carport eyelet anchor bolt, M16 x 300Vendor: VectisSKU: A5001130Vectis Carport eyelet anchor bolt is part of the aluminium Waterproof Carport system, designed for mounting solar solutions on large, unused surfaces. It provides shaded, dry parking while supporting framed module installations. Vectis offers highly pre-assembled PV mounting systems, including aluminium ground mounting and...
-
Vectis Carport NW rail spliceVendor: VectisSKU: A5001050Vectis Carport NW Rail Splice is part of the aluminium Waterproof Carport and Ground Mount system, designed for efficient solar mounting. It ensures a secure and durable solution for both carport and ground-mount applications, optimising installation efficiency and system longevity. Vectis Carport: Waterproof structure...
-
Vectis Groundmount, aluminium angleVendor: VectisSKU: A4001120The Vectis Aluminium Ground Mounting System represents a cutting-edge solution for solar PV installations, designed to streamline installation processes while ensuring durability and reliability. Engineered with meticulous attention to detail, this system is ideal for various environmental conditions and compatible with commonly used PV...
-
Vectis Earthing clip, type AVendor: VectisSKU: A0001010Vectis Earthing clip, type A, is incorporated into both the Aluminium Ground Mounting and Rail-Less Metal Mounting Systems. Vectis Ground Mount provides a new, pre-assembled PV mounting system, such as this aluminium ground-mounting system. The pre-assembly of the main support beam makes installation more...
-
Vectis Bottom rail clampVendor: VectisSKU: A5001100Vectis Bottom rail clamp forms part of the aluminium Waterproof Carport and Ground Mount system. Vectis Carport This VECTIS product is a waterproof carport structure, ideal for mounting energy generation solutions on large surfaces that would otherwise go unused. Along with energy production, this...
-
Vectis Railless rooftop clamp IBRVendor: VectisSKU: A2001030VECTIS revolutionises the installation process of solar panels with its innovative design, featuring aluminium profiles with specialised hollow structures and connections. This design ensures effortless installation without the need for cumbersome rails. As a universal PV mounting solution, VECTIS caters to both commercial and...
