Description
xThe Noark Ex9BP-JX(-) 4-pole Mini Circuit Breaker is specifically designed for direct current (DC) applications up to 1000 V DC. With a robust 40 A rated current capacity, it ensures reliable protection for photovoltaic (PV), battery storage, and industrial DC circuits. Featuring a modular design, it supports efficient DIN rail mounting and safe, space-saving integration.
Key Features
- Designed for high-voltage DC applications up to 1000 V
- 4-pole configuration for enhanced system flexibility
- Rated current of 40 A, suitable for demanding loads
- High breaking capacity to ensure circuit protection
Specifications
xProduct Name
Noark Ex9BP-JX(-) Mini Circuit Breaker, 4-pole, 40 A
Poles
4-pole
Rated Current
40 A
Rated Voltage
1000 V DC
Breaking Capacity
6 kA (IEC 60947-2)
Tripping Curve
Type C (DC-optimised)
Mounting
DIN rail
Standards Compliance
IEC/EN 60947-2
Operating Temperature
–40 °C to +70 °C
Connection Type
Tunnel-type terminals
