Description
xThe Noark Ex9BP-JX(-) mini circuit breaker is engineered for reliable protection of DC circuits up to 250 VDC. Featuring a single pole and a rated current of 40 A, it offers robust overload and short-circuit protection in industrial and commercial applications.
Key Features
- Single-pole design for DC circuit protection
- Rated for up to 250 VDC voltage systems
- 40 A rated current suitable for medium load applications
- Compact size with DIN rail mounting for easy installation
The product conforms to the following compliance standards:
Specifications
xType
Mini Circuit Breaker
Series
Ex9BP-JX(-)
Poles
1
Operating Voltage
250VDC
Amperage
40A
Mounting Type
DIN Rail
Tripping Characteristic
B Curve
Breaking Capacity
10 kA
Certifications
UL 489, CSA C22.2 No. 5.1, IEC/EN 60947-2
